Denon AVR-1509 Owner's Manual

Surround mode
Signals and adjustability in the different modes
Channel output Parameter (default values are shown in parentheses)
Front L/R Center Surround L/R Subwoofer
D. Comp
z
1
LFE
z
1
Cinema EQ. Mode Room Size Effect Level Delay Time Subwoofer
DIRECT
S A A D S (OFF) S (0 dB) A A A A A S
STEREO
S A A D S (OFF) S (0 dB) A A A A A A
EXT. IN
S D D D A A A A A A A A
DOLBY PRO LOGIC g S D D D S (OFF) A
S
(OFF, NOTE1)
S A A A A
DTS NEO:6
S D D D S (OFF) A
S
(OFF, NOTE2)
S A A A A
DOLBY DIGITAL
S D D D S (OFF) S (0 dB) S (OFF) A A A A A
DTS SURROUND
S D D D A S (0 dB) S (OFF) A A A A A
5CH STEREO
S D D D S (OFF) S (0 dB) A A A A A A
ROCK ARENA
S D D D S (OFF) S (0 dB) A A S (Medium) S (10) A A
JAZZ CLUB
S D D D S (OFF) S (0 dB) A A S (Medium) S (10) A A
MONO MOVIE
S D D D S (OFF) S (0 dB) A A S (Medium) S (10) A A
VIDEO GAME
S D D D S (OFF) S (0 dB) A A S (Medium) S (10) A A
MATRIX
S D D D S (OFF) S (0 dB) A A A A S (30 ms) A
VIRTURL
S A A D S (OFF) S (0 dB) A A A A A A
S : Enable
A : Unable
NOTE1 : This parameter is available when “Surround Parameter” – “Mode” is set to “Cinema” or “PL” (
vpage 26).
NOTE2 : This parameter is available when “Surround Parameter” – “Mode” is set to “Cinema” (
vpage 26).
NOTE:
z
1 : When playing Dolby Digital and DTS signals.
S : Signal / Adjustable
A : No signal / Not adjustable
D : Turned on or off by speaker configuration setting
Surround Modes and Parameters

Getting Started Connections Setup Playback Remote Control Information Troubleshooting
ENGLISH
Specifications

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
