Input signal Display
Dolby
Digital
Source
DOLBY DIGITAL
(other than 2ch)
DOLBY DIGITAL
DTS
Surround
Source
DTS (5.1ch) /
DTS 96/24
DTS SURROUND
DTS 96/24 (z)
z : This is displayed when the input signal is “DTS 96/24”.
For details, see page 45.
To select these surround modes using <SELECT/ENTER> or press
[STD].
Playing Multi-channel Sources
(Dolby Digital, DTS, etc.)
In the case of standard playback of multi channel sources, the AVR-
1509 recognizes the format of the multi-channel audio input signal and
automatically operates the appropriate decoder for surround sound.
[Selectable items]
STANDARD
:
Any of the surround modes in the “Display” column in the following
table.
The mode changes depending upon factors such as the
Input signal
is being used.
Input signal
Display
Analog signal /
PCM (2ch) /
Dolby Digital source /
DTS source /
Other 2-channel digital signals
DIRECT
For details, see page 45.
e Direct Playback
r Stereo Playback
Selecting the mode
Select by turning <SELECT/ENTER> or pressing [D/ST].
[Selectable items]
STEREO
:
This is the mode for playing in stereo. The tone can be adjusted.
Sound is output from the front left and right speakers and subwoofer.
Selecting the mode
Select by turning <SELECT/ENTER> or pressing [D/ST].
[Selectable items]
DIRECT
:
In this mode the signals bypass the tone adjustment circuitry for high
quality sound.
The sound is output to the same channels as the input signal.
Depending on the program source being played, it may not be possible
to achieve a satisfactory surround effect. In this case, try other modes
to achieve a sound field suited to your tastes.
w DSP Simulation Playback
The desired mode according to the program source and viewing
situation can be selected from among 7 DENON original surround
modes.
The surround parameters can be adjusted (vpage 43, 44) to
achieve an even more realistic, powerful sound field.
Selecting the surround mode
Select by turning <SELECT/ENTER> or pressing [SIMU].
[Selectable items]
5CH STEREO
z1
: This mode is for enjoying stereo sound from all
speakers.
ROCK ARENA
: This mode is for enjoying the atmosphere of a
live concert in an arena.
JAZZ CLUB
: This mode is for enjoying the atmosphere of a
live concert in a jazz club.
MONO MOVIE
z2
: This mode is for playing monaural movie sources
with surround sound.
VIDEO GAME
: This mode is suited for achieving surround
sound with video games.
MATRIX
: This mode lets you add a sense of expansion to
stereo music sources.
VIRTUAL
: This mode is for enjoying surround effects using
only the front speakers or headphones.
z1 : Can also be selected by pressing [5CH].
z2 : When playing sources recorded in monaural in the MONO MOVIE
mode, the sound will be off balance with a single channel (left or
right), so input to both channels.

Getting Started Connections Setup Playback Remote Control Information Troubleshooting
ENGLISH
Specifications

Table of Contents
