Denon AVR-1509 Owner's Manual

Surround mode
Signals and adjustability in the different modes
Parameter (default values are shown in parentheses)
PRO LOGIC g MUSIC mode only
NEO:6 MUSIC
mode only
EXT. IN only
Tone Control
(NOTE5)
Night Mode
(NOTE5)
MultEQ
Dynamic EQ
(NOTE6)
Dynamic Volume
(NOTE7)
DV Setting RESTORER
Panorama Dimension Center Width Center Image
SUBWOOFER
ATT.
DIRECT
A A A A A A S (OFF) S (OFF, NOTE4) S (ON, NOTE4) S (OFF, NOTE4) S (Midnight, NOTE8) A
STEREO
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
EXT. IN
A A A A S A A A A A A A
DOLBY PRO LOGIC g S (OFF) S (3) S (3) A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
DTS NEO:6
A A A S (0.3) A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
DOLBY DIGITAL
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) A
DTS SURROUND
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) A
5CH STEREO
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
ROCK ARENA
A A A A A S (NOTE3) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
JAZZ CLUB
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
MONO MOVIE
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
VIDEO GAME
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
MATRIX
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
VIRTURL
A A A A A S (0 dB) S (OFF) S (OFF, NOTE9) S (ON, NOTE9) S (OFF, NOTE9) S (Midnight, NOTE8) S (OFF, NOTE10)
S : Adjustable
A : Not adjustable
NOTE3 : BASS +6 dB, TREBLE +4 dB
NOTE4 : When “System Setup” – “Option Setup” – “Direct Mode Setup” are turned “ON”, also after implementing “Auto Setup”.
NOTE5 : This parameter is not availabe when “Surround Parameter” – “Dynamic EQ” is set to “ON” (vpage 27).
NOTE6 : This parameter is not availabe when “Surround Parameter” – “MultEQ” is set to “OFF” (vpage 27).
NOTE7 : This parameter is not availabe when “Surround Parameter” – “Dynamic EQ” is set to “OFF” (vpage 27).
NOTE8 : Displayed when “Dynamic Volume” setting is “ON”.
NOTE9 : Displays after implementing Auto Setup.
NOTE10 : Displayed when input signal is “Analog” or “PCM 44.1/48 kHz”.

Getting Started Connections Setup Playback Remote Control Information Troubleshooting
ENGLISH
Specifications

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
