Denon AVR-1509 Owner's Manual

Symptom Cause Countermeasure Page
No sound is
produced from
center speaker.
• You are playing a monaural
source (TV, AM radio broadcast,
etc.) in the “STANDARD” (Dolby/
DTS Surround) mode.
• The mode is set to something
other than “STANDARD” (Dolby/
DTS Surround).
24
No sound
is produced
from surround
speakers.
• The surround mode is set to
“STEREO” or “DIRECT”.
• Set to a surround playback
mode.
24
No sound is
produced from
subwoofer.
• Subwoofer’s power not turned
on.
• The “Subwoofer” setting at
“Speaker Configuration” is set to
“No”.
• The subwoofer is not properly
connected.
• The subwoofer’s volume is
turned off.
• Turn on the subwoofer’s power.
• Set to “Yes”.
• Check the connections.
• Adjust the subwoofer’s volume
to an appropriate level.
–
19
8
36
No test tones are
produced when
remote control
unit’s TEST button
is pressed.
• Surround mode not set to
“ S TA N D A R D ” ( D o l b y / D T S
Surround).
• Set to the “STANDARD”(Dolby/
DTS Surround) mode.
24
DTS sound is not
output.
• DVD player’s audio output setting
is not set to bitstream.
• DVD player is not compatible
with DTS sound playback.
• The AVR-1509’s “Input Mode”
setting is set to other than
“DTS”.
• Set the DVD player. For details,
refer to the DVD player’s
operating instructions.
• Use a DTS-compatible player.
• Set to the “Auto” or “DTS”
mode.
–
–
30
GAudioH
Symptom Cause Countermeasure Page
No picture
appears.
• The connections between the
AVR-1509 and monitor are faulty.
• The monitor’s input setting is
wrong.
• The player is connected using the
component input connectors, the
monitor is connected using the
video (yellow) or S-Video output
connectors.
• Check the connections.
• Set properly.
• In the case of a player which
is connected to component
terminals, if the monitor is not
connected to the component
terminals, the image will not
appear. Check the connections.
9 ~ 12
–
–
DVDs cannot be
copied on a VCR.
–
• This is not a malfunction. Most
movie software includes copy
prevention signals and cannot be
copied.
–
GVideoH
Symptom Cause Countermeasure Page
HDMI audio
signals are not
output from
speakers.
–
• The audio signal input to the
HDMI input connector cannot be
played on the AVR-1509. Input
the audio signal to the digital
audio input connector or analog
audio input connector.
9, 11
No picture
appears
with HDMI
connections.
• The connections to the HDMI
connectors are faulty.
• HDMI input setting is improper.
• The HDMI format of the player
and monitor do not match.
• Check the connections.
• Check the HDMI input setting.
• Match the HDMI format of the
player and monitor.
9, 11
21
9, 11
No sound is
output from
the monitor
connected
with HDMI
connections.
• HDMI input setting is improper. • Check the HDMI input setting. 21
GHDMIH
Symptom Cause Countermeasure Page
iPod cannot be
played.
• The input source assigned to
control dock for iPod is not
selected.
• Cable is not properly connected.
• Control dock for iPod’s AC
adapter is not connected to
power outlet.
• Switch to the input source
assigned at control dock for
iPod.
• Reconnect.
• Plug the control dock for iPod’s
AC adapter into a power outlet.
21
11
–
GiPodH

Getting Started Connections Setup Playback Remote Control Information Troubleshooting
ENGLISH
Specifications

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
