Getting Started Connections Settings Playback Remote ControlMulti-zone Information Troubleshooting SpecificationsConnections
Connecting Devices
R
L
R
L
"6%*0
"6%*0
3-
065
$0"9*"-
065
CD player
Turntable
(MM cartridge)
Record PlayerCD Player
Select the terminal to use and connect the device.
The AVR-4810CI is compatible with record players with an MM
cartridge. When you connect to a record player with an MC
cartridge, use a commercially available MC head amp or a step-up
transformer.
When you increase the volume without connecting the record player,
there may be “booming” noise from the speakers.
•
•
NOTE
The SIGNAL GND terminal of the AVR-4810CI is not a safety ground
connection. Connect it to reduce noise when noise is excessive.
Note that depending on the record player, connecting the ground line
may have the reverse effect of increasing noise. In this case, it is not
necessary to connect the ground line.
Set this to change the input signal to which the input source is
assigned.
“Input Assign” (vpage 58)
Set as Necessary
Control dock for iPod
Set other than when iPod is assigned to the VCR (iPod) terminal.
“Input Assign” – “iPod dock“ (vpage 60)
Set as Necessary
Control Dock for iPod
Use a DENON control dock for iPod (ASD-1R or ASD-11R, sold
separately) to connect the iPod to the AVR-4810CI. For instructions on
the control dock for iPod settings, refer to the control dock for iPod’s
operating instructions.
With the default settings, the iPod can be used connected to the
VCR (iPod) connector.
You can also connect the iPod you are using directly to the USB port
of the AVR-4810CI (vpage 24 “USB Port”).
•
•
To Next Page
