Denon AVR-X1000 User Manual

139
Appendix
TipsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Settings
3
Connect the Setup and measurement microphone to
the SETUP MIC jack of this unit.
When the Setup and measurement
microphone is connected, the
following screen is displayed.
Audyssey Setup
Your AVR can automatically measure the
acoustics of your room and the optimize
your speakers.
Start
4
Select “Start” and then press ENTER.
5
Select “Next” and then press ENTER.
6
Select “Begin Test” and then press ENTER.
•Measurement requires several minutes.
NOTE
•If “Caution!” is displayed on TV screen:
Go to “Error messages” (vpage 143). Check any related items, and
perform the necessary procedures.
When measuring has stopped
q Press BACK to display the popup screen.
w Press o to select “Yes”, and then press ENTER.

Denon AVR-X1000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Ethernet LAN (RJ-45) ports	1
Multichannel audio output type	RCA
Connectivity technology	Wired
AM antenna ports quantity	0
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPS
Wi-Fi	No
Supported radio bands	FM
Internet radio services supported	vTuner
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPhone
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	390 W
Cables included	AC

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	151 mm
Weight	8200 g
