Denon AVR-X1000 User Manual

140
Appendix
TipsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Settings
7
The detected speakers are displayed.
Audyssey Setup
Repeat Last Test Next
Front
Speaker Detection
Center
Subwoofer
Surround
Yes
Yes
Yes
Yes
8
Select “Next” and then press ENTER.
9
Move the Setup and measurement microphone to
position 2, select “Continue”, and then press ENTER.
The measurement of the second position starts. Measurements
can be made in up to eight positions.
Audyssey Setup
Place the microphone at ear level at the 2nd
Listening position.
Continue
Calculation
Back
%
•To skip measuring the second and subsequent listening position, use i to
select “Calculation” and press ENTER to proceed to step 12.

Denon AVR-X1000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Ethernet LAN (RJ-45) ports	1
Multichannel audio output type	RCA
Connectivity technology	Wired
AM antenna ports quantity	0
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPS
Wi-Fi	No
Supported radio bands	FM
Internet radio services supported	vTuner
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPhone
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	390 W
Cables included	AC

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	151 mm
Weight	8200 g
