APPENDIX II
2D IMAGER
The tables below list the symbology settings for 2D imager.
SYMBOLOGY SETTINGS
1D SYMBOLOGIES
Symbology Description Default
CODABAR
CodaBar Enable
Codabar Switch to enable Codabar decoding. Enable
Length option Sets the length of the Codabar symbols to decode.
 One Fixed length (Length 1)
 Two Fixed lengths (Length 1>Length 2)
 Max / Min Length (range: 0-55; Length 1<Length 2)
 Any Length
Max / Min
Length
(4-55)
CLSI Editing
When applied, the CLSI editing strips the start/stop
characters and inserts a space after the first, fifth, and
tenth characters of a 14-character Codabar barcode.
 The 14-character
barcode length does not include
start/stop characters.
Disable
NOTIS Editing
Sets whether to include start/stop characters in the
transmitted data.

NOTIS Editing is to strip the start/stop characters, i.e.
to disable “Transmit Start/Stop Characters”.
Disable
NOTIS Editing Type Options are None, ABCD/ABCD, abcd/abcd.
“NOTIS Editing” must be enabled.
None
Verify Check Digit Selects whether to verify the Modulo 43 check digit. If the
check digit is incorrect, the barcode will not be accepted.
None
