15
Power
Line Power Supply
From L1 Phase to L2 Phase. 80-600V (AC or DC) CAT III DC/50/60Hz, 125 mA, 5 W, or
10 VA max.
Non-user replaceable .5 Amp internal fuse protection.
Power In (optional) 6-10 VDC maximum, 500 mA minimum
Mechanical
Operating Temperature -7 to + 60°C (20 to 140°F)
Humidity 5% to 95% non-condensing
Enclosure ABS plastic, 94-V0 flammability rating
Weight 340 g (12 ounces, excluding sensors and leads)
Dimensions 69 x 58 x 203 mm (2.7” x 2.2” x 8.0”)
Minimum System Requirements
Operating System Windows® 7 (32 or 64 bit), Windows® 8, Windows® 10 or Vista (32 or 64 bit)
Processor Pentium Class 1 GHz or more recommended
Hard Drive 50 MB minimum available
Communications Port One USB port required for logger connection and ELOG software installation
