35
Communicating with the ELITEpro XC
1) Plug the USB cable into the logger and the PC. ELOG 15 should auto-launch and connect to the
ELITEpro XC automatically. If not, double-click the ELOG icon on the PC desktop.
The ELOG window opens,
displaying the menus and a
row of speed buttons to
quickly access frequently
used ELOG functions.
The ELITEpro XC and ELOG 15 software should connect
automatically. If not, proceed with Step 2 below. If the
automatic connection is made, proceed with Step 6
below.
2) Select Tools > PC Setup to open the ELOG PC Setup dialog
box
.
3) In the middle section of the dialog box labeled Direct Connect, select the Port from the menu that
c
orresponds to the computer’s COM port where the USB cable is connected
.
Port Preferences: This option is used to hide COM Ports from ELOG, to change the order of COM
Ports as they appear in the drop-down control, and the order they are searched when ELOG can't
connect to a logger on the desired port.
ID
OU
NOW
up the PC by clicking on the PC
Setup speed button. ELOG
provides the user with “Friendly
Ports™” in the Port drop-down list
as a convenient way to identify
where connections can be made.
