DENT Instruments ELITEpro XC User Manual

33
CONNECTING THE USB CABLE
1) C
onnect the USB cable to an available USB port on the computer and insert the other end in the
COM port of the ELITEpro XC
.
I
f a USB cable is used inside an electrical panel, it must be rated to the appropriate voltage or wrapped
in an appropriately-rated insulating sleeve. The DENT-supplied cable does not meet this requirement
without an insulating sleeve.
2) Turn the breaker on.
P
ower End Panel Connections
USB Port
Power In/Out
w ww. . com
