55
Mini
Small
Split Core
Midi
Medium
Split Core
Large Split
Core
Clamp-
on
RōCoil
(Rogowski)
20A
5A/15A
(high
accuracy)
100A 100A 600A 150A 5,000A
50A 50A 200A 200A 1000A 500A
RōCoil mV
Various
sizes available.
Contact DENT
Instruments.
100A 400A 1000A
600A
Current Ratings of CTs Available from DENT Instruments
All of the CTs in the table are available from DENT Instruments.
These are internally shunted CTs (333.3 mV output) which
make them safe to handle even when connected to an
energized wire. They are also case-insulated for 600V phase-to-
phase service. Do not use on services with higher voltages.
The following table is a list of the UL recognized (61010-1) CTs
that can be used to maintain the UL listing.
High
Performance
20A Mini
High
Performance
50A Mini
High
Performance
100A Midi
High
Performance
200A Midi
RōCoil
(Rogowski)
CT-HSC-020-U CT-HSC-050-U CT-HMC-0100-U CT-HMC-0200-U CT-RXX-1310-U
CT-HSC-020-B CT-HSC-050-B CT-HMC-0100-B CT-HMC-0200-B CT-RXX-A4-U
UL Recognized CTs
CAUTION: DO NOT USE UNSHUNTED CTs. ONLY USE SHUNTED CTS WITH 333 mVAC OUTPUT. ALL
DIAGRAMS IN THIS SECTION SHOW THE CT PHASING ARROW POINTING TOWARD THE LOAD.
ID
OU
NOW
the leads for a RōCoil up to 100
feet and a split core up to 1000
feet without loss of accuracy,
provided that the new wire is of
the same size or larger than the
