VII. The pedelec and its components
*
VII.I Impulse Evo pedelec
1 Rear light
2 Luggage rack
3 Seat post
4 Saddle
5 brake lever right
(rear wheel brake)
6 Shifter (rotary grip*)
7 Handlebar stem
8 Handle bars
9 brake lever left
(front wheel brake)
10 Easy-reach control
11 Impulse Evo (Smart)
display
12 Front light
13 Suspension fork
14 Disc brake
(front wheel)*
15 Front wheel hub
16 Tyre
17 Wheel rim
18 Pedal
19 Motor
20 Pedal crank
21 Chain/Belt
22 Reectivestripe
23 Side stand*
24 Axle nut
25 Reector
26 Seat Stays
27 Battery Include and
dockingstation
28 Seat tube
29 Down tube
30 Top tube
31 Disc brake
(rear wheel)*
32 Chargers
4
86
14
13
15
16
171819
3
9
2
5
1
23
24
22
21
25
28 2926
31
30
7
10
20
11
12
27
32
*dependent on model
