Original User Guide | Pedelec Impulse Evo / Impulse Evo Next Version 4 EN-59
1. In the main menu, navigate to the option “Display ride data” as
described under  6.4.1.2 Navigating within a menu Page EN-54.
2. Select the required option using the
/
buttons.
The option selected is highlighted. A box on the right shows how far
you can scroll up and down.
3. Brieypressthe
button to return to the main menu.
Main menu Sub-level Sub-level 2 Sub-level 3
Settings
Device settings Shift unit Shift strategy ON
OFF
Adjustment -2.50 mm to 2.50 mm
Change Shift Cable The shift unit is now in the gear cable
replacement position. You can remove the cable
and/or readjust it. Please press SET to end.
Slope sensor Please bring bike into straight position. Start
calibration?
Version
6.4.3.1 Impulse Evo (Smart) display: Display ride data
You can display the following menu options in the “Show ride data” main
menu option:
Menu options Meaning
Trip (in km) Trip (e.g. day trip, short trip) in kilometres.
Trip time (in 00:00:00
format)
Duration of trip (e.g. day trip, short trip) in hours, minutes and
seconds.
Trip max. (in km/h) Maximum speed (in kilometres per hour) achieved on the trip
(e.g. day trip, short trip).
Trip Ø (in km/h) Average speed (in kilometres per hour) achieved on the trip
(e.g. day trip, short trip).
Tour (in km) Tour (e.g. cycle tour over several days) in kilometres.
Tour Ø (in km/h) Average speed (in kilometres per hour) achieved on the tour
(e.g. cycle tour over several days).
Total (in km) Total number of kilometres ridden.
