Desoutter CVI3 Function User Manual

Appendix - I/O and events_02/2017 - 23 -
Name Description Raising condition Falling condition
Batch running A batch process is underway.
The output is set to 1 before the rst tightening operation.
A batch operation is
enabled
Batch is nished or
reset input
Batch nished Indicates when the batch count equals the batch size and the
batch is declared completed.
It is used together with "Batch OK" to indicate the status of a
batch.
Batch is nished. New start (tool trigger
or external start) or
reset input
Batch OK Indicates the status of the batch together with the "Batch
nished" output (managed by Assembly Process).
Batch is nished and
OK.
New start (tool trigger
or external start) or
reset input
Batch NOK Such as when the batch gets aborted…or in the case rejects
are included as part of the batch count (managed by Assembly
Process).
Batch is nished and
NOK.
A new AP has been
selected.
New start (tool trigger
or external start) or
reset input
Max retries
reached
Indicates when max number of retries is reached. Max number of retries
is reached.
Max number of
retries is reset.
External outputs AP
External Out
AP bit
Outputs that can be set or reset within an Assembly Process Depending of AP
behavior
Depending of AP
behavior
External outputs PLC
External Out
PLC bit (0..9)
Indicates this output is controlled by a PLC via Fieldbus (like a
remote I/O).
On PLC side, it is an output.
Depending on PLC
behavior
Depending on PLC
behavior
External outputs OP
External Out OP
bit (0..9)
Outputs dedicated to Open Protocol. Depending on OP
behavior
Depending on OP
behavior
Socket tray
Socket
selectable (0..4)
24 V socket trays (BSD).
Informs which socket can be taken by the operator.
A new socket has to
be taken by the user.
No socket to be taken
by the user.
Customized protocol Status
Customer
protocol
activated
A customer protocol has been activated in conguration Protocol is enabled Protocol is disabled
Customer
protocol
connected
The activated customer protocol is connected Protocol is connected Protocol is
disconnected
Customer
protocol
reporting alarm
The activated customer protocol has declared an alarm about
result reporting of this Tightening Unit.
Alarm is raised Alarm is cleared
Q_SAS ACK start tightening job - -
RDY Controller ready - -
Q_LSN Reverse disabled - -
WGZ Tool disabled - -
Q_EDZ Result and reports reset - -
Q_XMS XML data transfer completed - -
EIO Result OK - -
ENO Result NOK - -
FSCIO Group status OK - -
FSCNIO Group status NOK - -
CVILOGIX
External Out
CVILogix bit
(0..100)
Indicates that this output can be used by an internal CVILOGIX
application.
- -
Miscellaneous
ON On state, used to set level "1" to physical outputs. At controller startup. Never falls
OFF Off state, used to set level "0" to physical outputs. At controller startup. Never falls
