Desoutter CVI3 Function User Manual

Appendix - I/O and events_02/2017- 26 -
Name Description Status
Assembly Process commands
Assembly Process
selection bit (0-7)
Used to select an Assembly Process.
These inputs must be in the desired state BEFORE the activation of the assembly process
start input.
Rising edge
Abort assembly
process (tightening
unit)
The "Abort assembly process" input stops the Assembly Process being processed.
The Assembly Process is nished.
The Assembly Process result is memorized as "aborted" and “AP aborted” and "AP NOK"
events are set.
Rising edge
Batch-1 The "Batch-1" input allows the operator to select the previous operation of a batch
whatever the result of the next operation.
The batch counter is decremented.
The action is recorded OK or NOK according to the result and "Batch-1 event" is set.
Rising edge
Batch+1 In case you cannot complete the current operation of a batch, jump to the next one by
using the external input "Batch+1".
The action is declared as NOK and "Batch+1" event is set.
Rising edge
Restart batch Restarts the current batch of the current Assembly Process step.
The "Restart batch" event is set.
Rising edge
Reset number of
retries
Reset the number of retries counter.
If the max counter has been reached, the tool is unlocked.
Rising edge
External inputs AP
External in AP bit
(0..9)
Inputs used in Assembly Process in start conditions or in assembly actions sense input Rising edge
External inputs PLC
External In PLC bit
(0..9)
Indicates this input can be used by an PLC via Fieldbus (like a remote I/O).
For PLC side, it is an input.
State
External inputs OP
External In Open
Protocol 1-8
Inputs used in Open Protocol. They can be monitored from the Open Protocol client
by subscription. Theses DigIn are named "External monitored 1..8" in Open Protocol
specication.
State
Socket tray
Socket lifted bit (0..4) Used with CVI II controllers only: 24V socket trays (BSD).
Informs which socket has been lifted.
State
Customized protocol commands
PFCS END OF
CYCLE
Input used in PFCS Chrysler to ush the result FIFO when the operator has completed the
work
Rising edge
SAS Starts tightening job State
RST Resets any running tightening job State
LSN Disables reverse State
TOL Tool validation State
STR Tool start State
EDZ Resets results State
XMS Synchronous XML State
XMA XML activated State
CVILOGIX
External In CVILogix
bit (0..100)
Indicates that this input can be used by an internal CVILOGIX application State
