DS2460Q QAM Analysis Meter Operation Manual
95
Figure 4-76
The PING function parameters introduction.
HOST ADDRESS: Input the network address or the
desired IP address to be tested in the host address
box at the top (for example: www.google.com).
PACKET COUNT: the number of data packets sent by
the assigned PING order.
UNLIMITED: if this box is checked, the PING function
will be continuous until the test is interrupted by
pressing the stop button.
PACKET LENGHT: the package length: of the PING
request
INTERVAL: time interval delay between ping packets,
