DS2460Q QAM Analysis Meter Operation Manual
48
4.5 8VSB Measurement(Option)
If you want to use DS2460Q demodulate ITU-T J.83D
8VSB signal, you must do these operation:
SETUP->CHANNEL PLAN->EDIT USER PLAN->
F3
(EDIT)->SIGNAL: DVB-C->STANDARD: J.83D. or LEVEL,
QAM,BER screen, press the
F1
(CH INFO) to directly
modify one channel parameters.
The channel information as show in the Figure 4-35.
Figure 4-35
The 8VSB power and constellation test screen
snapshot as show in the Figure 4-36 and Figure 4-37.
