Deviser DS2460Q User Manual

DS2460Q QAM Analysis Meter Operation Manual
72
4.13.1 Soft Keys Operation
50Hz/60Hz(
F1
):After pressing 50Hzor 60Hz soft key,
the DS2460Q will select the frequency of system
power as Figure 4-53.
Figure 4-53
The buttons
and
2 DFE
are used to switch
analog channels circularly. Also you can input the
channel number using the character/digit keys (need use
0 F CN
button).
SAVE: Press
4JKL
button and enter into Figure 4-79
to save the result of tilt test ,refer to 4.21.2.
