4.7.2 Level List Mode
Press
F1
to switch the modes between Tilt Graph
and level list. In level list mode, you can easily get
level value of the channels tested, as Figure 4-43.
Soft Keys Operation
LIST(
F1
): Press GRAPH soft key to enter Tilt mode,
as Figure 4-42.
SAVE (
F2
):Press SAVE soft key and enter into Figure
4-79to save the result of tilt test ,refer to4.21.2.
SETUP(
F3
):When testing, press SETUP soft key and
enter into Figure 4-41to re-select tested channels.
Here, the
1 ABC
and
3 GHI A
button is defined to switch
the tilt channel which’s test result will be displayed at
the bottom of screen.
A FAIL or PASS will be displayed at the bottom of the
screen, the Limit value can be modified in
