DS2460Q QAM Analysis Meter Operation Manual
55
4.7.1 Tilt Mode
In tilt test interface, the channels will be displayed as
histogram, and test result will be displayed at the
bottom of screen as Figure 4-42.
Figure 4-42
Soft Keys Operation
LIST(
F1
): Press LIST soft key to enter level list mode,
as Figure 4-43.
