DS2460Q QAM Analysis Meter Operation Manual
30
Figure 4-13
NOTE: The analog channels with level higher than
-15dBmV and digital channel with power level
higher than -28dBmV will be enabled in
standard channel plan. Only the enabled
channels will be displayed in each
measurement interface. After setup your user
channel plan, you can also enable or disable
channels. When the learning the channel plan,
please keep the power on and don’t interrupt
the process, otherwise it will create a wrong
channel plan.
