KRYPTON® 

TECHNICAL REFERENCE MANUAL 



5.3. AO: Analog Out 

Single channel analog output module has a BNC connector and is the perfect module for sensor 

external excitation. 

5.3.1. AO: speciﬁcations 



KRYPTON-1xAO 

Analog Output 

Output types 

Voltage 

Number of channels 

1 

Output connector 

BNC 

DAC Resolution 

18 bit 

Update Rate 

1000 S/sec (see 1) 

Full Scale Output Range 

±10 V (see 2) 

Accuracy (typ.) 

0.1 % ±1 mV (0 to 20 mA load) 

Temperature gain drift (typ.) 

±10 ppm/K 

Temperature offset drift (typ.) 

±5 uV/K 

SNR @ 1000 S/s output rate 

92 dB (sine wave, 250 Hz, ±9 V) 

THD 

-90 dB 

Output impedance 

0.45 Ω DC 

Maximum output current 

20 mA 

Settling time (0.05 % of set value) 

30 μs @ 1000 Ω load, -10 V to 10 V step 

Max slew rate 

2.5 V/μs @ 1000 Ω load 

Max capacitive load (2 % overshoot) 

10 nF 

Maximum load 

500 Ω 

Output protection 

Short circuit protected 

Isolation 

- 

Power 

Power consumption 

2 W (typ.) 

Environmental 

IP rating 

IP65 / IP67 (see 3) 

Physical 

Dimensions 

62 x 56 x 29 mm 

Weight 

250 g 

1) Only asynchronous mode is supported in Dewesoft, function generator is not supported 

2) Only DC output voltage, function generator not supported 

3) Depending on the mating connector types 

 

KRYPTON® V20-1 39 / 141  
