KRYPTON® 

TECHNICAL REFERENCE MANUAL 



Bridge ranges 

20…10000 mV/V free programmable 

Internal Bridge Completion 

½ bridge and ¼ bridge 120 and 350 Ω 

Bridge Completion Accuracy 

0.05 %; TCR: 2 ppm/K (others on request) 

Internal Shunt Resistor 

100 kΩ (others on request) 

Shunt Resistor Accuracy 

0.1 %; TCR: 10 ppm/K (others on request) 

Input Short, Sensor Offset Adjust 

Software-selectable 

Power 

Power consumption 

2.8 W (typ.) 

Physical 

Dimensions 

62 x 56 x 29 mm 

Weight 

250 g 



5.11.2. KRYPTON-6xSTG 

KRYPTON-6xSTG module has 6 DSUB-9 female connectors for voltage or strain measurement. 



KRYPTON-6xSTG 



5.11.3. KRYPTON-6xSTG-L2B10f 

KRYPTON-6xSTG-L2B10fs module has 6 LEMO L2B10fs connectors for voltage or strain measurement. 



KRYPTON-6xSTG-L2B10f 

 

KRYPTON® V20-1 73 / 141  
