KRYPTON® 

TECHNICAL REFERENCE MANUAL 



5.5. CNT: Counter 

Single channel KRYPTON counter module utilizes a patented technology called SUPERCOUNTER in            

every of its counter/encoder inputs and in the smallest possible form. It supports counting, waveform               

timing, encoder, tacho, gear-tooth sensor. 

5.5.1. CNT: speciﬁcations 



KRYPTON-1xCNT 

Counter 

Input type 

Digital 

Number of channels 

1 

Input connector 

LEMO 1T series 7-pin 

Timebase 

100 MHz 

Time base accuracy 

Typical: 5 ppm, Max: 20 ppm 

Max. bandwidth 

10 MHz 

Input Filter 

500 ns, 1 μs, 2 μs, 4 μs, 5 μs and 7.5 μs 

Input Level Compatibility 

TTL (Low: < 0.8 V, High > 2 V) 

Input impedance 

100 kΩ pull-up to +3.3 V 

Input Protection 

±25 V continuous 

Sensor supply 

5 V / 100 mA, 12 V / 90 mA 

Isolation 

- 

Non-Isolated Sensor Power Supply 

Output Voltage +5 V 

5 V +/- 10 % 

100 mA max. 

Output Voltage +12 V 

12 V +/-10 % 

90 mA max. 

Power 

Power consumption 

1.2 W (typ.) 

Physical 

Dimensions 

62 x 56 x 29 mm 

Weight 

250 g 



 

KRYPTON® V20-1 45 / 141  
