5.8.2. KRYPTONi-8xLA 
KRYPTONi-8xLA has 8 BNC input connectors for current measurement. 

KRYPTONi-8xLA 
5.8.3. LA: connectors 


BNC connector: pin-out (BNC) 

Pin 
Name 
Description 
1 
In+ 
Input + 
2 
GND 
Ground 

