KRYPTON® 

TECHNICAL REFERENCE MANUAL 



KRYPTONi-4xDI 

Digital Inputs 

Input type 

Digital 

Number of channels 

4 

Connector 

DSUB15HD Male 

Compatibility 

TTL / CMOS Voltage Levels 

Input low level 

UIN < 1 V 

Input high level 

UIN > 2 V 

Input high current @ 5 V UIN 

3 mA typ. 

Input high current @ 30 V UIN 

6 mA typ. 

Propagation delay 

< 1 μs 

Max. sampling rate 

40 kS/sec 

Overvoltage protection 

30 V Continuous, 65 V peak 

Isolation 

Galvanic isolation CH, GND 

Non-Isolated Sensor Power Supply 

Output Voltage +5 V 

5 V +/- 10 % 

300 mA max. (see 1) 

Output Voltage +12 V 

12 V +/-10 % 

100 mA max. (see 1) 

Output Voltage +Vecat 

EtherCAT Bus Supply Voltage 

200 mA max. (see 1) 

Power 

Power consumption 

1.5 W (typ.) 

Physical 

Dimensions 

62 x 56 x 29 mm 

Weight 

250 g 

1) Max. combined load on +5 V and +12 V pins: 1.5 W reduced by the load already present on +Vin pin 



 

KRYPTON® V20-1 48 / 141  
