KRYPTON® 

TECHNICAL REFERENCE MANUAL 



KRYPTONi-1xLV 

Analog input 

Input types 

Voltage 

Number of channels 

1 

Input connector 

BNC 

ADC Type 

24-bit SAR with anti-aliasing ﬁlter 

Sampling Rate 

Simultaneous 40 kS/sec per channel (software-selectable) 

Voltage Ranges 

±50 V 

±10 V 

±1 V 

±100 mV 

Input Accuracy 

±0.03 % of reading, ±0.02 % of range, ±0.1 mV 

Typical SNR @ 10 kS/s 

96 dB 

94 dB 

88 dB 

Typical Dynamic Range @ 10 kS 

-130 dB 

-132 dB 

-137 dB 

-138 dB 

Typical Noise ﬂoor @ 10 kS 

-108.3 dB 

-102.6 dB 

-107.2 dB 

-100.1 dB 

Gain Drift 

Typical 10 ppm/K (max. 40 ppm/K) 

Offset Drift 

Typical 0.3 μV/K + 5 ppm of range/K, max 2 μV/K + 10 ppm of range/K 

Gain Linearity 

< 0.02 % 

Input Coupling 

DC, AC 1 Hz 

Input Impedance 

1 MΩ 

20 MΩ 

Overvoltage Protection 

200 V 

50 V 

Isolation 

125 Vrms channel to ground isolation 

Analog input performance 

Bandwidth (-3 dB) 

0.49 fs 

Alias-free Bandwidth 

DC to 0.453 fs 

Alias Rejection 

-100 dB (all sample rates) 

Delay Through ADC 

37 / fs 

Oversampling 

32 

Power 

Power consumption 

1.5 W (typ.) 

Physical 

Dimensions 

62 x 56 x 29 mm 

Weight 

250 g 

 

KRYPTON® V20-1 62 / 141  
