area
option
description
IOModule-X.
<port>
Audio Inputs
Type of
Signal
Shows the general signal type of the port.
Enter Label
Enter a distinctive name for the selected input.
Level Adjust
Choose the headroom for each input from the corresponding drop-down menu. The shown
values always refer to the devices internal default level of 0 dBint.
Select M/S
Select, if the signal is mono or stereo.
Sample Rate
Converter
Select from the drop down menu, if the sample rate converter is activated (
On
) or
deactivated (
Off
) for this input.
Add to Input
Pool
Select this check box to make this signal available for a channel on the console
Fader Start
Level
Select a level, which sets the fader start logic to on.
Auto Off
By closing the fader, the channel is automatically switched
OFF
(
ON
key is deactivated).
On Start
The faderstart is only activated and deactivated by pushing the On/Off key, not by moving
the fader.
Timer Reset
If this check box is selected, opening this fader will reset and start the
Auto
timer of the
stopwatch.
Channel On
Logic
Select a Logic Function from the
Logic Sources
window, which sets the channel to ON.
You can choose, for example a GPI to open a channel.
Channel Off
Logic
Select a Logic Function from the
Logic Sources
window, which sets the channel to OFF.
You can choose, for example a GPI to close a channel.
