Configuration
Specifications and design are subject to change without notice. The content of this document is for information only. The information presented in this document does not form part
of any quotation or contract, is believed to be accurate and reliable and may be changed without notice. No liability will be accepted by the publisher for any consequence of its use.
Publication thereof does neither convey nor imply any license under patent rights or other industrial or intellectual property rights.
area
option
description
…
IOModule-X.
<port>
Audio Inputs
Mute
Condition
Logic
Click
Source
to select a Logic source, that mutes the input, if the logic source becomes
true.
Mute Logic
1,2
Here, you can define which mute logics are enabled when opening a fader. Mostly, this
assignment is used to mute speakers when opening microphone channels. You can control up
to two mute logics. To do this, select the corresponding check boxes.
To assign a mute logic to an output select the mute logic check box at a selected output on
this tab.
Selector List
1
Select this check box to add this audio source to source list 1. This Source will be available
for monitoring in the
Selector
list, which is available in the
Selector
view of the TFT/
Touch Display.
Selector List
2
Select this check box to add this audio source to source list 2. This Source will be available
for monitoring in the
Monitor 2
list, which is available in the
Selector
view of the TFT/
Touch Display.
IOModule-X.
<port>
Audio
Outputs
Type of
Signal
Shows the general signal type of the port.
Enter Label
Enter a distinctive name for the selected output.
Headroom
Choose the headroom for each output from the corresponding drop-down menu. The shown
values always refer to the devices internal default level of 0 dBint.
Select M/S
Chose, if the signal is mono or stereo.
Sample Rate
Converter
Select from the drop down menu, if the sample rate converter is activated (
On
) or
deactivated (
Off
) for this output.
Dithering
If you connect devices with a lower resolution of the digital signals to a DHD device, here you
can define how the internal audio signal is to be dithered before leaving the digital output.
With this function, the quality of the output signal can be improved. You can select
16 bit
,
20 bit
, or
Off
(no dithering, preset value).
