Series 52 - 52/DX Compact Mixing Console Manual
Specifications and design are subject to change without notice. The content of this document is for information only. The information presented in this document does not form part
of any quotation or contract, is believed to be accurate and reliable and may be changed without notice. No liability will be accepted by the publisher for any consequence of its use.
Publication thereof does neither convey nor imply any license under patent rights or other industrial or intellectual property rights.
…
IOModule-X.
<port>
Audio
Outputs
This option can adopt the values
Pro
(default value) or
Consumer
. The following
parameters are changed accordingly:
Especially for consumer and semiprofessional DAT
or MiniDisc devices, you should use the
Consumer
option, because they might not synchronise
properly in which case they display
No Lock
, for
example.
You can assign an audio signal to a mono output.
Click the
Source
button, the
Audio sources
window opens. Select an audio source,
and click
Assign
.
You can assign an audio signal to the left channel of the selected output.
Click the
Source
button, the
Audio sources
window opens. Select an audio source,
and click
Assign
.
You can assign an audio signal to the right channel of the selected output.
Click the
Source
button, the
Audio sources
window opens. Select an audio source,
and click
Assign
.
Select this check box to enable volume control for the headphones via a potentiometer which
is connected to an ACI.
This option is only available for headphone outputs. The ACI on D-sub port 1 is assigned to
headphone 1 (HP1) and the ACI on D-sub port 2 is assigned to headphone 2 (HP2).
Select this check box to mute this output, if a fader with one of the inputs with selected
Mute Logic 1
check box is opened.
Select this check box to mute this output, if a fader with one of the inputs with selected
Mute Logic 2
check box is opened.
