Digi XBee3 802.15.4 User Manual

AT commands I/O settings commands
Digi XBee3® 802.15.4 RF Module User Guide
108
Parameter Description
1
Keeps device awake for 30 seconds.
4
Restore defaults (equivalent to sending an RE command).
Default
N/A
D1 command
Sets or displays the DIO1/ADC1/TH_SPI_ATTN configuration (Micro pin 30/SMT pin 32/TH pin 19).
Parameter range
SMT/MMT: 0, 2 - 5
TH: 0 - 5
Parameter Description
0 Disabled
1
SPI_ATTN for the through-hole device
N/A for surface-mount device
2 ADC
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D2 command
Sets or displays the DIO2/ADC2/TH_SPI_CLK configuration (Micro pin 29/SMT pin 31/TH pin 18).
Parameter range
SMT/MMT: 0, 2 - 5
TH: 0 - 5
Parameter Description
0 Disabled
1
SPI_CLKfor through-hole devices
N/A for surface-mount devices
2 ADC
