AT commands I/O settings commands
Digi XBee3® 802.15.4 RF Module User Guide
112
Parameter Description
2
PWM0 output. M0 command or I/O line passing control the value.
3 Digital input
4 Digital output, low
5 Digital output, high
Default
1
P1 command
Sets or displays the DIO11/PWM1 configuration (Micro pin 8/SMT pin 8/TH pin 7).
When configured as PWM output (2): you can use M1 to explicitly control the PWM1 output. When used
with Analog line passing, PWM corresponds with ADC1.
Parameter range
0, 2 - 5
Parameter Description
0 Disabled
1 N/A
2
PWM1 output. M1 command or I/O line passing control the value.
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
P2 command
Sets or displays the DIO12/TH_SPI_MISO configuration (Micro pin 5/SMT pin 5/TH pin 4).
Parameter range
SMT/MMT: 0, 3 - 5
TH: 0, 1, 3 - 5
Parameter Description
0 Disabled
