Digi XBee3 802.15.4 User Manual

Frame descriptions AT Command Frame - 0x08
Digi XBee3® 802.15.4 RF Module User Guide
137
Frame data fields Offset Example
Frame ID 4 0x13
AT command 5 0x53 (S)
6 0x4C (L)
Parameter value (optional)
Checksum 8 0x45
The following example illustrates an AT Command frame when you modify the device's DL parameter
value to a broadcast address of 0xFFFF. A non-zero Frame ID can be used to correlate the AT
command request with the corresponding response frame.
Frame data fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x08
Frame type 3 0x08
Frame ID 4 0x4D
AT command 5 0x44 (D)
6 0x4C (L)
Parameter value 7-10 0xFF
0xFF
Checksum 11
0x1C
