Digi XBee3 802.15.4 User Manual

Frame descriptions RX Packet: 16-bit address I/O frame - 0x83
Digi XBee3® 802.15.4 RF Module User Guide
150
Frame data
fields Offset
Total
number
of
samples Description
Analog
samples
13 ADC0
MSB
If the sample set includes any ADC data, each enabled analog input
returns a two-byte value indicating the A/D measurement of that
input. ADC channel data is represented as an unsigned 10-bit value
right-justified on a 16-bit boundary. Analog samples are ordered
sequentially from AD0 to AD5.
14 ADC0
LSB
...
n - 1 ADCn
MSB
n ADCn
LSB
The following table shows the Channel Indicator bit field.
Bit field Description
Reserved 3 bits
A3 - A0 4 analog bits
D8 - D0 9 digital bits

Digi XBee3 802.15.4 Specifications

General

Module Type	XBee3
Protocol	802.15.4
Frequency Band	2.4 GHz
Data Rate	Up to 250 kbps
Range (Line of Sight)	1200 m
Operating Temperature	-40° C to +85° C
Security	AES-128
I/O Interfaces	UART, SPI, I2C
Antenna Options	U.FL
Power Supply	2.1 to 3.6 VDC
