Frame descriptions Transmit Status frame - 0x8B
Digi XBee3® 802.15.4 RF Module User Guide
157
Frame Fields Offset Example
Length MSB 1 0x00
LSB 2 0x07
Frame type 3 0x8B
Frame ID 4 0x47
Reserved 5 0xFF
6 0xFE
Transmit retry count 7 0x00
Delivery status 8 0x00
Reserved 9 0x02
Checksum 10 0x2E
