Frame descriptions Receive Packet frame - 0x90
Digi XBee3® 802.15.4 RF Module User Guide
159
Frame data fields Offset Example
Length MSB 1 0x00
LSB 2 0x12
Frame type
3 0x90
64-bit source address
MSB 4 0x00
5 0x13
6 0xA2
7 0x00
8 0x40
9 0x52
10 0x2B
LSB 11 0xAA
Reserved
12
0xFF
13
0xFE
Receive options 14 0x01
Received data 15 0x52
16 0x78
17 0x44
18 0x61
19 0x74
20 0x61
Checksum 21 0x11
