Digi XBee3 802.15.4 User Manual

OTA firmware upgrade process for 802.15.4 Image Block request
Digi XBee3® 802.15.4 RF Module User Guide
175
Frame data fields Offset Example Comments
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x1E
Frame Type 3 0x91
64-bit source address MSB 4 0x00
5 0x13
6 0xA2
7 0xFE
8 0x00
9 0x00
10 0x00
LSB
11
0x03
16-bit source address MSB
12
0x28
LSB
13
0x2F
Source Endpoint 14 0xE8
Destination Endpoint 15 0xE8
Cluster ID MSB
16
0x00
LSB
17
0x19
Profile ID MSB
18
0xC1
LSB
19
0x05
Receive options 20 0x01
