AT commands Network and security commands
Digi XBee3® 802.15.4 RF Module User Guide
81
Bit Meaning Setting Description
0
1
TX
compatibility
0
Transmissions are optimized as follows:
1. Maximum transmission size is affected by multiple factors (MM,
MY, DH, DL, and EE). See Maximum payload rules. In the best
case, with no app header, short source and destination
addresses, and no encryption, the maximum transmission size
is 116 bytes.
2. Multiple messages can be present simultaneously on the active
queue, providing they are all destined for different addresses.
This improves performance.
1
Transmissions operate like the Legacy 802.15.4 module, which means
the following:
1. Maximum transmission size is 95 bytes for encrypted packets
and 100 bytes for un-encrypted packets. These maximum
transmission sizes are not adjusted upward for short
addresses or for lack of an APP header.
2. Only one transmission message can be active at a time, even if
other messages in the queue would go to a different
destination address.
1 Node
Discovery
compatibility
0
Node discovery operates like other XBee devices and not like the
Legacy 802.15.4 module. This means the following:
1. A directed ND request terminates after the single response
arrives. This allows the device to process other commands
without waiting for the NT to time out.
2. The device outputs an error response to the directed ND
request if no response occurs within the time out.
1
The module operates like the Legacy 802.15.4 module, which has the
following effect:
1. When the expected response arrives, the command remains
active until NT times out. (NT defaults to 2.5 seconds.) This
prevents the device from processing any other AT command,
even if the desired response occurs immediately.
2. When the timeout occurs, the command silently terminates and
indicates success, whether or not a response occurred within
the NT timeout.
Default
0
1
This bit does not typically need to be set. However, when the XBee3 802.15.4 RF Module is streaming
broadcasts in transparent mode to a Legacy 802.15.4 module (S1 hardware), and RR > 0, set this bit to avoid a
watchdog reset on the Legacy 802.15.4 module.
