DigiPoS PowerPoS & Millennium Technical Manual
2D Hardware Acceleration Features
• ROP3 Ternary Raster Operation BitBLTs
• 8, 16, and 32 bpp mode acceleration
Motion Video Architecture
• High quality up/down adjustment
• Planar to packed format conversion
• Motion compensation for full speed DVD playback
• Hardware sub-picture blending and highlights
• Multiple video windows for video conferencing
• Contrast, hue, saturation, brightness and gamma controls
Flat Panel Monitor Support
• 12-bit digital interface for Flat Panel encoders
• Auto-expansion and centering for VGA modes
• Support for all resolutions up to 1280x1024
• Digital Visual Interface (DVI) 1.0 compliant
Concurrent PCI Bus Controller
• PCI 2.2 compliant, 32-bit 3.3V PCI interface with 5V tolerant inputs
• Supports up to 5 PCI masters
• PCI to system memory data streaming support
• Delay transaction from PCI master accessing DRAM
• Symmetric arbitration between Host/PCI bus for optimised system
performance
Full Software Support
• Drivers for major operating systems and APIs including
o Windows 9x
o Windows NT 4.0
o Windows 2000
o Windows 3.x
o OS/2 2.1/3.0 (Warp)
o Linux
• Direct3D, DirectDraw and DirectShow OpenGL ICD for Windows 9x, NT,
2000 and Xp
• North Bridge/Chipset and Video BIOS support
Onboard Audio
• AC’97 2.1 compliant codec
• 18-bit stereo full duplexcodec
• VSR (Variable Sampling Rate), 1Hz resolution
• 3D stereo expansion for simulated surround sound
• 1 stereo analog line-level input
• 1 mono analog line-level input
• 1 line-level output with volume control
• Multiple codec mode
• Low Power consumption mode
• Exceeds Microsoft® PC’9x requirements
Page 17 of 17
