DigiPoS PowerPoS & Millennium Technical Manual
Important Notes
1 For maximum performance, the cable used for the hard drive is constructed from a
special material and due care must be taken when removing or replacing this item,
taking note of the route the cable takes from the hard drive to the motherboard
connector.
2 As the power supply of this unit is an AT type, it will not support Advanced Power
Management (APM) functions. Under Windows 2000, if the APM function is enabled,
the system will not shut down correctly.
3 If the hard drive has to be replaced, only fit a hard drive that has a maximum speed
of 5400rpm. For the correct type and options available, please contact PC-PoS.
4 The only connectors that can be unplugged while the DigiPoS is powered are the
USB connectors. If any other connector is removed or replaced while the power is
on, serious damage can occur to the DigiPoS. This is considered to be outside the
scope of the warranty and will attract a charge for the repair of any damage caused
by this action.
5 The installation of an internal CD-ROM will determine the maximum card length used
in the 32-bit PCI SLOTS located in PCI 1/PCI 2 because of the compact nature of the
DigiPoS. The length of any PCI add-on card is as follows:
5.1 190mm long x 110mm wide without CD-ROM
5.2 140mm long x 110mm wide with CD ROM
5.3 The ISA SLOT has a maximum length of any add-on card of 170mm long x
110mm wide.
