DigiPoS PowerPoS & Millennium Technical Manual
PnP/PCI Configurations
Phoenix – AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
Item Help
PNP OS Installed [Yes]
Reset Configuration Data [Disabled]
Resources Controlled By [Auto(ESCD)]
x IRQ Resources Press Enter
x DMA Resources Press Enter
PCI/VGA Palette Snoop [Disabled]
Assign IRQ For VGA [Disabled]
Assign IRQ For USB [Enabled]
Menu Level ff
Select Yes if you are
using a Plug and Play
capable operating
system. Select No if
you need the BIOS to
configure non-boot
devices
ÇÈÆÅ: Move +/-/PU/PD: Value F10 : Save ESC : Exit F1 : General Help
F5 : Previous Values F6: Fail-Safe Defaults F7 : Optimised Defaults
Details
Feature Options Description
PNP OS Installed
Yes
No
Select Yes if the operating system environment is Plug-
and-Play compatible (e.g., Windows 9x).
Reset Configuration Data
Disabled
Enabled
Normally, this field is Disabled. Select Enabled to reset
Extended System Configuration Data (ESCD) when you
exit Set-up if you have installed a new add-on device and
the system reconfiguration has caused such a serious
conflict that the operating system cannot boot.
Resources Controlled By
Auto(ESCD)
Manual
The Plug and Play Award BIOS can automatically
configure all the boot and Plug and Play-compatible
devices. If you select Auto, all the interrupt requests (IRQ)
and DMA assignment fields disappear, as the BIOS
automatically assigns them.
IRQ Resources
Legacy ISA
PCI/ISA PnP
When resources are controlled manually, assign each
system interrupt as one of the following types, depending
on the type of device using the interrupt:
Legacy ISA
Devices compliant with the original PC AT
bus specification, requiring a specific interrupt (such as
IRQ4 for serial port 1).
PCI/ISA PnP
Devices compliant with the Plug and Play
standard, whether designed for PCI or ISA bus
architecture.
