DigiPoS PowerPoS & Millennium Technical Manual
Details Cont.
Feature Options Description
ECP Mode Use DMA
(If ECP Mode Selected)
1
3
Select a DMA channel for the parallel port for use
during ECP mode.
Parallel Port EPP Type
(If EPP Mode Selected)
EPP1.9
EPP1.7
You may have a device that requires an EPP parallel
port. When it does it will also state the EPP port
standard. Select it here as required.
Onboard Serial Port 3
Disabled
3F8H
2F8H
3E8H
2E8H
This item allows you to determine the access onboard
serial port 1/port 2 controllers have with which IRQ
and I/O address.
Serial Port 3 Use IRQ
IRQ3
IRQ4
IRQ5
IRQ7
IRQ9
IRQ10
IRQ11
This item allows you to determine the access onboard
serial port 1/port 2 controllers have with which IRQ
and I/O address.
Onboard Serial Port 4
Disabled
3F8H
2F8H
3E8H
2E8H
This item allows you to determine the access onboard
serial port 1/port 2 controllers have with which IRQ
and I/O address.
Serial Port 4 Use IRQ
IRQ3
IRQ4
IRQ5
IRQ7
IRQ9
IRQ10
IRQ11
This item allows you to determine the access onboard
serial port 1/port 2 controllers have with which IRQ
and I/O address.
Onboard Legacy Audio
Disabled
Enabled
Enables or Disables the onboard Multimedia device
Sound Blaster
Disabled
Enabled
Allows the multimedia device to run in a sound blaster
compatible mode. This may be necessary with some
software programs.
SB I/O Base Address
220H
240H
260H
280H
Selection for the Input/ Output base address of the
onboard multimedia.
SB IRQ Select
IRQ 5
IRQ 7
IRQ 9
IRQ 10
Selection for the IRQ address of the onboard
multimedia.
SB DMA Select
DMA 0
DMA 1
DMA 2
DMA 3
Select a DMA channel for the onboard multimedia to
use.
MPU-401
Disabled
Enabled
Select Enabled to configure the MPU-401 interface.
Page 56 of 56
