DG-FS1526 User Manual
Field Description
Threshold
The valid range is 1 ~ 63. This value indicates the number of broadcast
packets that are allowed to enter each port in one time unit. One time
unit is 50us for Gigabit speed, 500 us for 100Mbps speed, and 5000us
for 10Mbps speed.
Enable Port Select the corresponding port.
7.5 VLAN Configuration
In large networks, routers are used to isolate broadcast traffic for each subnet into separate
domains. This switch provides a similar service at Layer 2 by using VLANs to organize
any group of network nodes into separate broadcast domains. VLANs confine broadcast
traffic to the originating group, and can eliminate broadcast storms in large networks. This
also provides a more secure and cleaner network environment.
The system supports VLAN based on port and VLAN based on tag. You can change the
VLAN mode in the VLAN Mode page.
Choose VLAN Setting, and the sub-menus of VLAN Setting are shown as below.
27
