DG-
FS1526 User Manual
9
 Transmission distance: < 100m, Cat. 3/5 UTP. The transmission distance of SFP
port is determined by optical module.
 Auto-MDI/MDI-X. Automatically distinguish crossover cable from straight
through cable.
3.5 Ph
ysical Characteristics

Dimension (L x W x H):440 mm x 208 mm x 44 mm
 Net Weight: 2.9 kgs
 Gross Weight: 3.9 Kgs
4 Device Inst
allation and Description
4.1 Prep
aration Before Installation
4.1.1 Packag
e Contents

DG-FS1526 Fast Ethernet Switch
 Power Cord
 Bracket Mounting Kit containing two brackets and six screws for
attaching the brackets to the switch
 CD containing User Manual
 Four adhesive foot pads
4.1.2 Optional
Accessories and Tools

Screwdriver
 ESD straps
 Ethernet crimping pliers, 8P8C crystal heads
 Ethernet (either crossover or straight through) cable
