DG-FS1526 User Manual
Field Description
STP Mode
You can select it from the drop-down list:
Bridge Priority
The valid range is 0 ~ 61440. The lower integer value for
precedence indicates the higher priority. And the integer should
be a multiple of 4096.
Hello Time
The valid range is 1 ~ 10. The unit is second. The hello time
indicates the interval of transmitting BPDU.
Max Age
The valid range is 6 ~ 40. The unit is second. It is the longest
waiting time of the blocking state turning into listening state.
Max Age >= 2*(Hello Time+1)
Forward Delay
The valid range is 4 ~ 30. The unit is second. It is the longest
waiting time of the listening state turning into learning state or
the learning state turning into forwarding state.
2*(Forward Delay-1) >= Max Age
After proper configuration, click Submit to apply the settings. In the mean time, you can
view the STP bridge status.
47
