DG-FS1526 User Manual
49
Field Description
Port No. Select it from the drop-down list.
Priority The valid range is 0 ~ 240. It should be a multiple of 16.
RPC
Root Path Cost. The valid range is 1 ~ 200000000.
0 indicates Auto.
RPC determines the path cost that is from per port to root bridge. It is related with speed. The
following table lists the recommended value. You can modify it during actual using.
Speed IEEE Recommended Value Recommended Range
10Mbps 100 50~600
100Mbps 19 10~60
1000Mbps 4 3~10
10GMbps 2 1~5
After proper configuration, click Submit to apply the settings. In the mean time, you can
view the STP port status.
