DG-FS1526 User Manual
Field Description
System Priority The valid range is 1 ~ 65535.
Link Aggregation
Algorithm
You can select it from the drop-down list:
Member
The system supports three link groups.
Link Group 1: It includes the following ports: 1, 2, 3, 4.
Link Group 2: It includes the following ports: 5, 6, 7, 8.
Link Group 3: It includes the following ports: 25, 26.
State You can select Disable or Enable.
Type
You can select it from the drop-down list:
Operation Key
When the type is LACP, there are some protocol parameters. Such
as operation key, transmitting LACP packets interactively or not.
Time Out
You can select it from the drop-down list:
It is the time out of trunking, when the link port does not receive
the corresponding LACPDU.
Activity
You can select it from the drop-down list:
One switch should be set to Active between two switches.
53
