DG-SC2100/DG-SC2100W User Manual
10
LED Indicators description
LED Name Power Link Status Description
Booting
Flash
Flash
System Ready ON OFF
LAN connected ON ON
Data transferring ON Quick Flash
Activate WPS,
push the
WPS/Reset button
and release within
5 seconds.
ON Slow Flash The configuration should be
finished within 120 sec., after
which the Link Status LED will
go back to the original status.
Reset to default,
keep the
WPS/Reset button
pressed for more
than 10 seconds
Quick Flash ON The 2 LEDs will turn off when
reset to default takes effect and
the system will reboot.
