DG-SC2100/DG-SC2100W User Manual
30
The description of every setting in this menu will be given below:
Item Description
Network Type This camera can automatically obtain the IP address
from DHCP server (if available), or a fixed IP
address can be assigned to it. Select ‘DHCP’ to
obtain IP address automatically or ‘Static IP
Address’ to assign this IP camera with a fixed IP
address.
When ‘DHCP’ is selected, IP address parameters
below will be grayed out.
IP Address Specify the IP address for this IP camera here.
Subnet Mask Specify the subnet mask for this IP camera here.
Gateway Specify the gateway address of the local network
here.
Primary DNS Specify the IP address of DNS server here. Please
input IP address only. If you don’t know the address
of DNS server, ask network administrator or your
ISP for help.
Secondary DNS Specify the IP address of backup DNS server here.
When primary DNS is unreachable, IP camera will
use the IP address specified here as DNS server.
This field is optional.
AV Control Port Specify the port number used for video transfer. If
you have firewall on your network, you need to
allow computers on Internet to access the port
number of the IP address of IP camera, or you’ll not
be able to view video from Internet.
Web Port Specify the port number of web management
interface here. If it’s not 80, you’ll have to add
‘:port’ after the IP address / hostname of this IP
camera.
For example, if the HTTP port number you
specified here is 90 and the IP address of IP camera
is 10.20.20.30, then you have to input
‘http://10.20.20.30:90’ in the address bar of Internet
explorer.
Click ‘Apply’ to save settings and make the new settings take effect.
